Description
VK-B630D Four-sided planer for dry wood VK-B618D do drewna suchego.
Technical specifications:
| Specification | Value |
|---|---|
| Working width | 25–180 mm |
| Working thickness | 8–130 mm |
| Min. cutting length | 580 mm / 300 mm |
| Feeding speed | od 5 do 40 m/min |
| Total power | 38,25 kW |
| Main spindle speed | 7000 obr/min |
| Blade diameter | Φ40 mm |
| Sawblade diameter | Φ305 x Φ50 mm |
| Power on individual spindles: | Upper: 7,5 kW, Lower: 5,5 kW |
| Saw spindle motor power | 22 kW |
| Spindle lifting motor power | 0,75 kW |
| Press lifting motor power | 0,75 kW |
| Blade motor power | Left: 5,5 kW |
| Right: 5,5 kW | |
| Pierwsze górne: 7,5 kW | |
| Drugie górne: 5,5 kW | |
| Pierwsze dolne: 4 kW | |
| Drugie dolne: 5,5 kW | |
| Feeding motor power | 4 kW |
| Pneumatic source pressure | 0,6 MPa |
| Suction port diameter | 6 x Φ150mm |
| Weight | 3000 kg |
| Dimensions | 3770 x 1550 x 1660 mm |
